Application and performance characteristics of cooling curtains


Application of cooling curtains:

cooling system:

"wet curtain-Negative pressure fan" cooling system is composed of paper porous wet curtain, water circulation system and fan. When the unsaturated air flows through the surface of the porous, wet wet curtain, a large amount of water evaporates, and the sensible heat reflected by the temperature in the air is converted into latent heat of evaporation, thereby lowering the temperature of the air itself. When the fan is exhausted, the cold air cooled by the wet curtain will be continuously introduced into the room to achieve the cooling effect.

cooling wet curtainThe cooling is to continuously pump water from the water receiving plate through the circulating water pump, and spray it evenly on the evaporation filter layer through the water distribution system, so that the outdoor hot air passes through the evaporation heat exchanger (evaporation) Wet curtain) exchanges heat with water. The cooling effect is achieved by evaporation of water, and the clean air is pressurized by a low-noise fan and sent to the room for cooling. The effect is like standing on a beach in cool air.

Humidification system: cooling and damp When used as a humidifying medium, curtains are mainly used in special industries such as plantations and greenhouses that require high humidity. Because the wet curtain has the characteristics of water absorption, water resistance, fast diffusion, and good durability, it is suitable for adjusting indoor humidity.

Filter System: Wet Curtain It also has ventilation, ventilation and corrosion resistance. It has a good filtering effect on dirt in the air. It is a non-toxic, odorless, clean, humidified, and cool green material. It is also a medium for air purification filtration.

Drying wet curtain performance characteristics :

Texture45*45The degree is staggered. New polymer materials and space cross-linking technology;

High water absorption, high water resistance, mildew proof, long service life, long-term availability;

The cooling curtain has high evaporation efficiency, large surface area and good cooling effect;

No surfactant, naturally absorbing water, spreading fast, long-term use.

natural water absorption height60-70mm/5minutes,200 mm/hours, in line with world industry standards;

does not contain chemicals such as allergic phenol. It is non-toxic and harmless to the human body.

Green, safe, energy-saving, environmentally friendly, and economically applicable.

The intensity of the cooling curtain is high , no deformation.
